1 Hp Boat Lift Motor: Stainless Steel: Aqua Marine Supply

SKU

Original price $616.69 - Original price $616.69
Original price
$616.69
$616.69 - $616.69
Current price $616.69
Availability:
in stock, ready to be shipped

Boat Lift Motor

Marine Grade Electric Motor

A dependable boat lift starts with the right motor. This 1 HP stainless steel marine-duty motor is built for reliable performance and corrosion resistance in demanding waterfront environments.

Stainless Steel Housing

Designed to resist corrosion and hold up in harsh marine conditions.

Reliable Starting Power

Built with a start capacitor for dependable lift operation.

Marine Lift Rated

15-minute duty cycle engineered specifically for boat lift applications.

Install Ready

Includes shaft key for easier installation and setup.

Motor Overview

1 HP
Horsepower
115 / 230V
Voltage
1725 RPM
Speed
56 Frame
Frame
TENV
Enclosure
15 Minute
Duty Cycle

Specifications


Nameplate

HP1
Frame56
TypeC-Face
RPM1725
ShellStainless Steel
Volts115 / 230
Amps13.8 / 6.9
Hz60
Service Factor1.0
EnclosureTENV
Duty Cycle15 Minute

Additional

AMS P/N13200TE.SS
MPN13200TE.SS
Shaft Size5/8 inch
Key Size3/16 inch
Key IncludedYes
Capacitor TypeStart
Capacitor Size500 MFD 125V
Used OnE-Gear 4000, AMS4000
Country of OriginChina

Dimensions

Item Weight25.6 lb
Item Length10-1/2"
Item Width6-1/2"
Item Height8-1/2"
Packaged Weight30 lb
Packaged Dims17" × 12" × 12"

Need help choosing the right motor?

Not every lift uses the same motor setup. If you're unsure about compatibility, contact Dock Solutions before ordering and we’ll help you get the correct motor the first time.
